Genuine Intel Core 12th Gen i7 12700F Desktop Processor BX8071512700F

Essentials Product Collection 12th Generation Intel Core i7 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i7-12700F Lithography Intel 7 Use Conditions PC/Client/Tablet CPU Specifications Total Cores 12 # of Performance-cores 8 # of Efficient-cores 4 Total Threads 20 Max Turbo Frequency 4.90 GHz Intel Turbo Boost Max Technology 3.0 Frequency 4.90 GHz Performance-core Max Turbo Frequency 4.80 GHz Efficient-core Max Turbo Frequency 3.60 GHz Performance-core Base Frequency 2.10 GHz Efficient-core Base Frequency 1.60 GHz Cache 25 MB Intel Smart Cache Total L2 Cache 12 MB Processor Base Power 65 W Maximum Turbo Power 180 W Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s Expansion Options Direct Media Interface (DMI) Revision 4.0 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1 ?Œ ?‘16+4, 2 ?Œ ?‘8+4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 ?¥ ?¡C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian & Neural Accelerator 3.0 Intel Thread Director Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security & Reliability Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Warranty 3 Years
