Genuine INTEL CORE I3 10105 3.7 GHz QUAD CORE LGA 1200 PROCESSOR(BX8070110105)

Description INTEL CORE i3-10105 3.7 GHz QUAD-CORE LGA 1200 PROCESSOR(BX8070110105) The Core i3-10105 3.7 GHz Quad-Core LGA 1200 Processor from Intel has a base clock speed of 3.7 GHz and comes with features such as Intel Optane Memory support, Intel Boot Guard, Intel VT-d virtualization technology for directed I/O, and Intel Hyper-Threading technology. With Intel Turbo Boost 2.0, the maximum turbo frequency this processor can achieve is 4.4 GHz. Additionally, this processor features 4 cores with 8 threads in an LGA 1200 socket, has 6MB of cache memory, and 16 PCIe lanes. Having 4 cores allows the processor to run multiple programs simultaneously without slowing down the system, while the 8 threads allow a basic ordered sequence of instructions to be passed through or processed by a single CPU core. This processor also supports 128GB of dual-channel 2666 MHz DDR4 RAM and utilizes 10th-generation technology. Graphically, the Core i3-10105 uses the integrated Intel UHD Graphics 630 chipset, which has a base frequency of 350 MHz and a dynamic frequency of 1.15 GHz. A thermal solution is included and protection is provided by a limited 3-year warranty. General CPU Model Intel Core i3-10105 CPU Socket LGA 1200 Manufacturing Process 14 nm Maximum CPU Configuration 1S Maximum Number of PCIe Lanes 16 (Revision 3.0) Unlocked No Performance Number of Cores 4 Number of Threads 8 Base Clock Speed 3.7 GHz Maximum Boost Speed 4.4 GHz L3 Cache 6 MB Memory Support Maximum Capacity 128 GB Memory Support DDR4 2666 MHz ECC Memory No Channel Architecture Dual Channel Maximum Memory Bandwidth 41.6 GB/s Power Thermal Design Power (TDP) 65 W Included Thermal Solution PCG 2015C Maximum Temperature 212 ?°F / 100 ?°C Thermal Monitoring Technologies Yes Technology AES Support Yes Extension AVX 2.0, SSE 4.1/4.2 Instruction Set 64-Bit Virtualization Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) Integrated Graphics Graphics Chipset Intel UHD Graphics 630 Maximum Resolution Support 4096 x 2304 at 60 Hz Supported APIs DirectX: 12 OpenGL: 4.5 Number of Displays 3 Maximum Shared Video Memory 64 GB Output Support eDP, DisplayPort, HDMI Base Clock Speed 350 MHz Maximum Boost Speed 1.15 GHz Intel DMI DMI3 (8 GT/s) Optane Memory Support Yes vPro Support No Performance Technologies Hyper-Threading, SpeedStep, Turbo Boost 2.0 Security Technologies Device Protection with Boot Guard, Execute Disable Bit, Identity Protection, OS Guard, Secure Key, Software Guard Extensions Video Technologies Clear Video, Clear Video HD, InTru 3D, Quick Sync Video Packaging Info Package Weight 0.725 lb Box Dimensions (LxWxH) 5 x 4 x 2.9 ?€³
